ELLIX-30/40 PRINTING METHOD:
Direct thermal line printing
ELLIX-30 PRINTING SPEED:
MONO PAPER 80mm = Max. 180mm/sec (43 line/sec)
MONO PAPER 58mm = Max. 150mm/sec (36 line/sec)
TWO COLOR PAPER = Max. 100mm/sec (24 line/sec)
ELLIX-40 PRINTING SPEED:
MONO PAPER 80mm = Max. 220mm/sec (52 line/sec)
MONO PAPER 58mm = Max. 150mm/sec (36 line/sec)
TWO COLOR PAPER = Max. 100mm/sec (24 line/sec)
ELLIX-30/40 RESOLUTION:
180 dpi
ELLIX-30/40 PRINTING WIDTH:
Mono Paper 80mm = Max. 72.0mm
Mono Paper 58mm = 48mm(Max. 54mm)
ELLIX-30/40 PRINT FONT:
FONT A Domestic = 24*24
FONT A Foreign = 12*24
FONT B Domestic = 16*16
FONT B Foreign = 9*17
COLUMN CAPACITY (FONT A) Domestic = 21(80mm)/15(58mm)
COLUMN CAPACITY (FONT A) Foreign = 42(80mm)/30(58mm)
COLUMN CAPACITY (FONT B) Domestic = 28(80mm)/20(58mm)
COLUMN CAPACITY (FONT B) Foreign = 56(80mm)/40(58mm)
CHARACTER SIZE (FONT A) Domestic = 3.38(W)*3.38(H)mm
CHARACTER SIZE (FONT A) Foreign = 1.69(W)*3.38(H) mm
CHARACTER SIZE (FONT B) Domestic = 2.25(W)*2.25(H) mm
CHARACTER SIZE (FONT B) Foreign = 1.26(W)*2.39(H) mm
CHARACTER SET = 95 Alphanumeric, 37 International,128*11 Graphic, Korean.
ELLIX-30/40 PAPER:
LOADING = Drop-In Type
DIMENSION = Max. 58.0/80.0 x ¦83.0mm
THICKNESS = 0.06~0.08 mm
ELLIX-30/40 AUTO CUTTER:
Guillotine Type (Jamfree)
ELLIX-30/40 MEMORY:
PGM Memory = 2 Mbyte
Data Memory = 8 Mbyte
Data Buffer(Domestic&Foreign) = 64KB
ELLIX-30/40 RELIABILITY:
MECHANISM(MCBF) = 70,000,000 lines
TPH = 1x108 Pulse, 150 KM
AUTO CUTTER = 1,500,000 cut
ELLIX-30/40 BARCODE:
UPC-A, UPC-E, EAN8, EAN13, Code 39, Code 93, Code 128, ITF, CODABAR, PDF417, QR Code.
ELLIX-30/40 DRIVER:
Windows 98/ 2000/ XP/ Vista(*86)/ 7/ 8/ 10, 2003 Server Driver, OPOS Driver
ELLIX-30/40 DRAWER PORT:
2 PORT (+24V)
ELLIX-30 INTERFACE:
USB+RS-232, USB+PARALLEL
ELLIX-40 INTERFACE:
USB Only, USB+RS-232, USB+PARALLEL, USB+ETHERNET, USB+WIFI, USB+BLUETOOTH
ELLIX-30/40 POWER SUPPLY:
SMPS Adapter/IN: AC 90~264V /OUT: DC 24V 2.5A
ELLIX-30/40 SENSOR:
PAPER NEAR END = YES (STAND and WALL)
PAPER END = YES
Cover Open = YES
ELLIX-30/40 OVERALL DIMENSION (WITH FOOT RUBBER):
144(W) x 195(L) x 137(H)mm
ELLIX-30/40 MASS(APPROX.):
NET (ONLY SET) = 3.0 Kg
WITH PACKING = 3.4 Kg
ELLIX-30/40 REGULATION:
EMC Domestic = CE marking,MIC
EMC Foreign = FCC class A, CE marking
SAFETY = TUV/GS,CE,CB,cTUVus
ELLIX-30/40 BODY COLOR:
Dark Gray or IVORY
ELLIX-30/40 EMULATION:
Epson, Star
ELLIX-30/40 TWO COLOR PRINTING:
YES
ELLIX-30/40 OPERATING CONDITION:
TEMPERATURE:
OPERATING = 5¡É ~ 45¡É
STORAGE = - -10¡É ~ 50¡É
HUMIDITY:
OPERATING = 30% ~ 80%(RH)
STORAGE = 10 ~90%(RH) : Except for Paper
OPTION:
Wall mount kit = YES
Paper seperater (58.0mm) = YES
Kitchen Bell = YES
ELLIX-30 LCD Display = NO
ELLIX-40 LCD Display = YES
Splash Cover = YES
